Hydraulic Diesel Forklift Truck 2.5 Ton Pneumatic Tyre Rough Terrain Forklift
Diesel Forklift truck 2.5ton 3ton 5ton 10ton Rough Terrain Forklift
Product Description of Diesel Forklift truck 7.0T Diesel Forklift Truck
rough terrain forklift for cheap sale
Rough Terrain Forklift is widely used in the mountains, plateaus pavement ,snow operations, construction sites , mines ,orchards pastures , rough roads and mining enterprises.
| Model | | FD25RT2 | FD30RT2 | FD35RT2 | FD50RT4 | FD70RT4 | FD100RT4 |
| | Power | | Diesel |
| | Load capacity | KG | 2500 | 3000 | 3500 | 5000 | 7000 | 10000 |
| Feature | Load center | mm | 500 | 600 |
| | Lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| | Service weight | kg | 4200 | 4320 | 4810 | 8250 | 8250 | 14500 |
| | Speed Travel(Unladen) | Km/h | 19.5 | 16 | 22 | 20 | 20 | 29 |
| | Speed Lifting(Laden) | mm/s | 372 | 372 | 300 | 300 | 300 | 187 |
| | Max.gradeability | % | 25 | 25 | 22 | 20 | 20 | 20 |
| | Work pressure | Mpa | 14 | 14 | 14 | 16 | 16 | 18 |
| | Min.Ground clearance | mm | 260 | 260 | 145 | 300 | 300 | 390 |
| Demension | Battery | V/h | 12/105 | 12/105 | 12/135 | 12/105 | 12/105 | 24/100 |
| | Wheel base | mm | 1175 | 1750 | 2080 | 2190 | 2190 | 2745 |
| Engine | Model | | 495 | 4D32G31-059 | 4D32G31-059 | 4DX21-72 | 4DX22-96 | WP6G125E22 |
| | Place of Origin | | XIHCHAI | XINCHAI | XINCHAI | FAW | FAW | DEUTZ |
| | Number of cylinders | | 4TNE98 | 4 | 4 | 4 | 4 | 6 |
| | Output power | KW | 42 | 36.8 | 36.8 | 57 | 70.6 | 92 |
| | Model | | 4TNE98 | 4TNE98 | 4TNE98 | 4BTA3.9-C100 | 4BTA3.9-C100 | 4BTA3.9-C130 |
| | Place of Origin | | Yanmar | Yanmar | Yanmar | Cummins | Cummins | Cummins |
| Engine | Number of cylinders | | 4 | 4 | 4 | 4 | 4 | 6 |
| | Output power | Kw | 42 | 42 | | | | |
Advantage:
1. Flexible hydraulic steering system.
2. Security to meet off-road conditions
3. Large ground clearance through sexual, minimum ground clearance vehicle reaches 220mm,through greatly increased.
4. Body large, irregular and large hungry can carry cargo; high ground clearance, can cross the obstacles on the site.
5. Full hydraulic steering system, greatly reducing operator fatigue; using transverse cylinder steering mechanism, steering reliable, compact.
6. Off-road design lengthened and widened lengthened wheelbase and wider front and rear track, vehicle stability; drive axle with multi-fetal, more suitable for off-road conditions.
7. Air filter with a vacuum alarm, double filtration; external high exhaust silencer, the external protective shield against hot processing; setting reversing buzzer, make driving safer.
8 .Comfort humanized design uses multifunction steering, European -style instruments, and equipped with car cigarette lighter; excellent damping performance seat belts, side-mounted joystick, so easy to operate ,safe ,flexible.
Machine Parts
1. Air filter
Air filter with a vacuum alarm, double filtration; external high exhaust silencer, the external protective shield against hot processing; setting reversing buzzer, make driving safer.
2. Engine
Yanmar , Xinchai , Cummins , Deutz engine
3. Multifunction steering
Comfort humanized design uses multifunction steering, European-style instruments, and equipped with car cigarette lighter; excellent damping performance seats with seat belts, side-mounted joystick, so easy to operate, safe, flexible .
4. Cab and headlight
The cab is equipped with air conditioning and headlight
Packaging & Shipping
One 20fcl container can load 4 units and one 40HC can lod 6 units ,by sea
The photo of Diesel Forklift truck 7.0T Diesel Forklift Truck
FAQ
1. How long it will take to deliver the products after I pay for it?
Above delivery time is 26 days.
2. What is the payment term?
Our Payment: T/T, L/C, etc.
3. How long is the warranty period of your equipment’s?
1 year.
4. What are your main products?
Counterbalanced electric forklift, electric pallet stacker, electric pallet truck, electric reach truck, electric tow tractor, order picker.
5. Can you customize the product?
Yes, we are a professional storage equipment company integrating design, production and sales, have a very professional team of designers and technical engineers, can customize the equipment according to your requirements.
6. How about the quality of your products?
We have a professional quality control department to monitor the whole production process; have CE,ISO9001 certification; provide online support at any time.
