Sinotruk 16m3 Powder Spreader Truck Road Binding Agent Spreader Truck
Road Binding Agent Spreader Truck can save a lot of manpower and material resources used in construction. In the traditional powder spreading process, it is completely completed by manpower, and the manpower input is large, and the spreading effect is poor. With the increase of labor costs and construction safety protection costs, the cost of manual powder spreading is constantly increasing. The use of powder spreader to spread powder can greatly improve production efficiency, maximize the speed of construction, and make the entire construction machinery team work more orderly.
Advantages:
a) High degree of intelligence;
b) No need to re-calibrate the metering system
c) Accurate measurement
d) Good spreading quality
e) The Road Binding Agent Spreader Truck adopts a pulse dust removal device for the powder material feeding link, which improves the dust removal effect of the feeding material, and also extends the service life of the dust removal filter element, and avoids the trouble of manual blowing and secondary pollution.
f) Convenient and simple operation: the entire working process can be operated by one driver;
g) High reliability
h) Spreading width and density are adjustable
i) Wide application range: Road Binding Agent Spreader Truck can not only be used for spreading cement for cold recycling construction on old roads, but also for spreading various adhesives in roadbed stabilized soil, and can also be used for spreading powdery materials in other occasions;
Technical specifications:
| Name | Unit | Data | Remark |
| Powder tank volume | L | 16000 2 | |
| Max. total mass | kg | 25000 | |
| Curb weight | kg | 16060 | |
| Full load axle load mass | kg | 9000/16000 | |
| Dimensions (LxWxH) | mm | 9105×2550×3365 | |
| Approach / departure angle | ° | 16/18 | |
| Minimum ground clearance | mm | 284 | |
| Back overhang | mm | 1805 | |
| Spreading width | mm | 500~2500 | adjustable |
| Spreading density | kg/ m2 | 3～40 | adjustable |
| Spreading accuracy | % | ±5 | |
| Speed of work | km/h | 2.6 | |
| Engine power | kW | 247 | 1900rpm |
| Driving speed | km/h | 80 | |
| Name | qty | unit | Remark |
| chassis | 1 | set | Howo |
| Powder box assembly | 1 | set | |
| Electric vibrator | 1 | set | Italy |
| Screw conveyor assembly | 3 | set | |
| Filter element | 12 | pcs | |
| cylinder | 6 | pcs | AirTAC |
| Rotary resistance level gauge | 4 | pcs | |
| Cycloid motor | 1 | pcs | Eaton |
| Hydraulic system | 1 | set | |
| variable pump | 1 | pcs | Rexroth (import) |
| Gear pump | 1 | pcs | parker |
| transfer case | 1 | set | |
| Cycloid motor | 3 | set | Eaton |
| Open core multi-way valve | 1 | pcs | Rexroth (import) |
| Closed core multi-way valve | 1 | pcs | Rexroth (import) |
| Hydraulic oil tank assembly | 1 | set | Including suction/return oil filter, air filter, liquid level liquid temperature gauge, etc. |
| Hydraulic cooler | 1 | pcs | |
| transmission shaft | 1 | pcs | |
| Sprocket drive assembly | 3 | pcs | |
| Hydraulic fittings | 1 | set | Weikete |
| Hydraulic hose | 1 | set | |
| Hydraulic steel pipe | 1 | set | |
| Pneumatic system | 1 | set | |
| Filter pressure reducing valve | 1 | pcs | |
| Three-position five-way solenoid valve | 1 | group | Include base |
| Air connection | 1 | set | |
| Pulse valve | 2 | pcs | |
| PU tube | 1 | set | |
| Electrical System | 1 | set | |
| PLC | 1 | pcs | Siemens |
| touch screen | 1 | pcs | |
| Amplifier | 2 | pcs | Rexroth (imported) |
| Girder accessories | 1 | set | |
| Spread mask | 1 | set | |
